Repair information 4-25
4512-630
Link developer drive and access door removal
1.
Remove the main motor drive. See “Main motor drive removal” on page 3-28.
2. Remove the coupling assembly. See “Developer drive coupling assembly removal” on page 3-16.
3. Disconnect the front access door from its hinges. See “Front access cover removal” on page 3-2.
Note: The cover does not need to be electrically disconnected.
4.
5.
Disconnect the link and door.
6. Remove the developer link.
