Diagnostic aids 3-19
4512-630
OUTPUT BIN TESTS
Feed Tests (output bins)
Use these tests to verify that media can be fed to a specific output bin. Media is fed from the default input source
to the selected output bin. No information is printed on the media fed to the output bin because the printhead is
not engaged during this test. These tests can use any media size or envelope supported by the printer.
To run the Feed Tests for the output bins:
1. Select Feed Tests from the OUTPUT BIN TESTS.
2. Select the output bin you want the paper to exit into. The standard bin as well as any output option bin
installed on the printer is shown on the menu. (The output bins are displayed in the order installed on the
printer.)
3. Select either Single or Continuous.
• Single–feeds one sheet of media from the selected source.
• Continuous–media continues feeding from the selected source until Stop ( ) is pressed.
Press Back ( ) to return to OUTPUT BIN TESTS.
Sensor Test (standard output bin)
This test is used to verify if the standard bin sensor is working correctly.
To run the Sensor Test for the standard bin:
1. Select Sensor Test from OUTPUT BIN TESTS.
2. Select Standard Bin from Sensor Tests.
3. Select NearFull or Full sensor to test.
The following screen is displayed:
Standard Bin x
Full=Open NearFull=Open
• Full–Bin full sensor
• NearFull–Bin near full sensor
4. Manually actuate the bin sensor by moving the flag in and out of the sensor. The display indicates Open
when the flag is out of the sensor and Closed when the flag is in the sensor.
5. Press Back () or Stop ( ) to exit the test.
