Repair information 4-7
4512-630
Top cover removal
1.
Remove the right side cover. See “Right side cover removal” on page 4-5.
2. Remove the left side cover. See “Left side cover removal” on page 4-4.
3. Open the rear door.
4. Remove the two screws (A) from the two front corners on the top cover, the two screws (B) from the two
rear corners on the top cover, and the screw (C) on the left side.
5. Open the front cover.
6. Remove the two screws (D).
7. Remove the controller card cover.
AB BC
D
