Lexmark MS517dn User Manual

• Maintenance kit, 100 V (40X8440)
• Maintenance kit, 110 V (40X8433)
• Maintenance kit, 220 V (40X8435)
• Forms and Barcode Card (41X0855)
• Forms and Barcode +
Simplified
Chinese Font (41X0857)
• Forms and Barcode + Japanese Font (41X0859)
• Prescribe Card (41X0840)
• IPDS card (41X0838)
• Relocation kit (40X8696)
April 5, 2019
• MarkNet Wireless Print Server FRU PN was changed from 40X8330 to 40X9939.
• Critical information for controller board or control panel replacement was added.
– Controller board removal was updated.
– Control panel assembly removal was updated.
– UICC removal was updated.
July 12, 2018
• For Performing the initial troubleshooting check, relative humidity values were updated (now 8 to 80%).
• A note for ambient temperature and relative humidity information was added to the Fuser service check.
April 27, 2018
• Updated the 24x error code tables in the Diagnostics and troubleshooting chapter.
• Updated the 24x.06 service check topic in the Diagnostics and troubleshooting chapter.
March 9, 2018
• Updated the Main drive gearbox service check under the Diagnostics and troubleshooting chapter.
December 19, 2017
• Updated the graphic for PN 40X9131 to include the MPF links in the assembly.
• Added PN 41X2300 for the access cover link under the Covers assembly in the Parts Catalog chapter.
• Added PN 40X9939 under Miscellaneous in the Parts Catalog chapter.
August 23, 2017
• Updated “Blank pages check” on page 43.
• Updated “Solid black pages check” on page 49.
May 31, 2017
• Updated 40X4827 to 40X9652 in the topic “Miscellaneous” in the “Parts catalog” chapter.
May 24, 2017
• Updated the "912 error messages" topic of the "912 errors" subgroup of the "Printer hardware errors" group
of the "Diagnostics and troubleshooting" chapter.
4514-6xx
Service conventions and change history
23

Lexmark MS517dn Specifications

General

Cables included	AC
Cartridge(s) included	Yes
Included cartridge capacity (black)	3000 pages
Color	No
Print technology	Laser
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	42 ppm
Duplex print speed (black, normal quality, A4/US Letter)	18 ppm
Processor cores	2
Noise level (idle)	15 dB
Processor frequency	800 MHz
Maximum internal memory	1280 MB
Sound pressure level (printing)	55 dB
Sound pressure level (duplex printing)	54 dB
Envelopes sizes	7 3/4, 9, 10, DL
Paper tray media types	Card stock, Envelopes, Labels, Plain paper, Transparencies
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Universal, Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Total input capacity	350 sheets
Total output capacity	150 sheets
Maximum input capacity	2000 sheets
Maximum number of input trays	5
Multi-Purpose tray input capacity	100 sheets
USB connector	USB Type-B
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Wi-Fi	-
Cabling technology	10/100/1000Base-T(X)
Security algorithms	LEAP, MD5, MSCHAPv2, PEAP, SNMPv3, SSL/TLS, TTLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols (IPv4)	TCP/IP IPv4, AppleTalk
Supported network protocols (IPv6)	TCP/IP IPv6, TCP, UDP
Package depth	472 mm
Package width	432 mm
Package height	380 mm
Package weight	16700 g
Power consumption (off)	0.5 W
Power consumption (ready)	7 W
Power consumption (printing)	600 W
Energy Star Typical Electricity Consumption (TEC)	2.1 kWh/week
Display	LCD
Certification	ENERGY STAR, Blue Angel RAL-UZ-171, ICES-003 Class B, BSMI Class B, VCCI Class B, US FDA, UL 60950-1, FCC Class B, cUL CAN/CSA-C22.2 60950-1, NOM, CB EN/IEC 60950-1, CB EN/IEC 60825-1, CE DoC (EN 62301 Class B, EN 62311, CE EN/IEC 60950-1, CE EN/IEC 60825-1, EN 61000-3, EN 55022 Class B, EuP, EN 55024, UL), EFTA (CE), KCC, CCC, CECP, CEL, C-tick DoC, UL-AR, KC mark, UL GS mark, EC 1275, MET-I, ISO 532B, ECMA-370, TED, GOST-R, SII, TER
Product color	Gray
Display diagonal	2.4 \
Printing colors	Black
Country of origin	China
Maximum duty cycle	120000 pages per month
Recommended duty cycle	1500 - 14000 pages per month
Page description languages	Microsoft XPS, PCL 5e, PCL 6, PDF 1.7, PPDS, PostScript 3
Sustainability certificates	Blue Angel, ENERGY STAR
Operating altitude	0 - 2896 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Authentication method	802.1x

Weight and Dimensions

Depth	382 mm
Width	399 mm
Height	263 mm
