Lexmark MS517dn User Manual

May 16, 2017
• Updated the entire group, “Fixing print quality issues” on page 40, which includes replacement of the
existing print quality icons with actual print defect outputs. Contents from the Service Manuals, KB and UG
articles are merged to come up with the new PQ checks.
April 24, 2017
• Added "MS517dn" and “MS617dn” in the cover.
• Added "MS517dn" and “MS617dn” in the introduction to the “General information" chapter.
• Added 41X2013 and 41X2017 to the revised topic "Control panel" in the "Parts catalog" chapter.
December 9, 2016
• Revised a graphic in the “Printhead assembly adjustments” topic in the “Repair information” chapter.
• Revised the “Laser scanning unit (LSU) removal” topic in the “Repair information” chapter.
• Added 41X1025 to the “Electronics 2” topic in the “Parts catalog” chapter.
November 21, 2016
• Changed 41X0005 to 40X8051 in the topic “Covers” in the “Parts catalog” chapter.
October 21, 2016
• Updated the topics “Unresponsive imaging unit service check” and “Blank pages check” in the “Diagnostic
information” chapter.
September 30, 2016
• Deleted the first two steps of the “Blank pages check” topic in the “Fixing print quality issues” group in the
“Diagnostic information” chapter.
August 17, 2016
• Moved topics on clearing jams under the topic “Understanding jam messages and locations” in the
“Diagnostic information” chapter.
• Updated the topic “Unresponsive imaging unit service check” in the “Diagnostic information” chapter.
• Updated the topic “Miscellaneous” in the “Parts catalog” chapter.
– Changed 40X8603 to 41X0855.
– Changed 40X8606 to 41X0856.
– Changed 40X8836 to 41X0857.
– Changed 40X8837 to 41X0859.
– Changed 40X8605 to 41X0840.
– Changed 40X8608 to 41X0860.
– Changed 40X8607 to 41X0858.
July 14, 2016
• Added the separator roll assembly in the ”Covers” topic in the “Parts catalog” chapter.
4514-6xx
Service conventions and change history
24

Lexmark MS517dn Specifications

General

Cables included	AC
Cartridge(s) included	Yes
Included cartridge capacity (black)	3000 pages
Color	No
Print technology	Laser
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	42 ppm
Duplex print speed (black, normal quality, A4/US Letter)	18 ppm
Processor cores	2
Noise level (idle)	15 dB
Processor frequency	800 MHz
Maximum internal memory	1280 MB
Sound pressure level (printing)	55 dB
Sound pressure level (duplex printing)	54 dB
Envelopes sizes	7 3/4, 9, 10, DL
Paper tray media types	Card stock, Envelopes, Labels, Plain paper, Transparencies
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Universal, Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Total input capacity	350 sheets
Total output capacity	150 sheets
Maximum input capacity	2000 sheets
Maximum number of input trays	5
Multi-Purpose tray input capacity	100 sheets
USB connector	USB Type-B
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Wi-Fi	-
Cabling technology	10/100/1000Base-T(X)
Security algorithms	LEAP, MD5, MSCHAPv2, PEAP, SNMPv3, SSL/TLS, TTLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols (IPv4)	TCP/IP IPv4, AppleTalk
Supported network protocols (IPv6)	TCP/IP IPv6, TCP, UDP
Package depth	472 mm
Package width	432 mm
Package height	380 mm
Package weight	16700 g
Power consumption (off)	0.5 W
Power consumption (ready)	7 W
Power consumption (printing)	600 W
Energy Star Typical Electricity Consumption (TEC)	2.1 kWh/week
Display	LCD
Certification	ENERGY STAR, Blue Angel RAL-UZ-171, ICES-003 Class B, BSMI Class B, VCCI Class B, US FDA, UL 60950-1, FCC Class B, cUL CAN/CSA-C22.2 60950-1, NOM, CB EN/IEC 60950-1, CB EN/IEC 60825-1, CE DoC (EN 62301 Class B, EN 62311, CE EN/IEC 60950-1, CE EN/IEC 60825-1, EN 61000-3, EN 55022 Class B, EuP, EN 55024, UL), EFTA (CE), KCC, CCC, CECP, CEL, C-tick DoC, UL-AR, KC mark, UL GS mark, EC 1275, MET-I, ISO 532B, ECMA-370, TED, GOST-R, SII, TER
Product color	Gray
Display diagonal	2.4 \
Printing colors	Black
Country of origin	China
Maximum duty cycle	120000 pages per month
Recommended duty cycle	1500 - 14000 pages per month
Page description languages	Microsoft XPS, PCL 5e, PCL 6, PDF 1.7, PPDS, PostScript 3
Sustainability certificates	Blue Angel, ENERGY STAR
Operating altitude	0 - 2896 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Authentication method	802.1x

Weight and Dimensions

Depth	382 mm
Width	399 mm
Height	263 mm
