LG MULTI V ARNU12GTRA4

Indoor unit
22 _ Ceiling Cassette 4-way
Indoor Units
Heating capacity
Notes:
TC: Total Capacity(kW)
1. Capacity tables show the representative value of conditions which may occur.
2. is shown as reference. When selecting the outdoor units, avoid the out-
door air temperature range shown by .
3. In accordance with operation limits of outdoor unit, applicable range of capac-
ity tables is different.
4. Refer to Capacity Correction Factorin the outdoor unit PDBfor the actual per-
formance data of each indoor unitand outdoor unit combination.
Capacity
Index
Outdoor air
temp.
DB(°C) WB(°C)
Indoor air temp. (DB, °C)
16 18 20 21 22 24
TC TC TC TC TC TC
kW kW kW kW kW kW
-24.8 -25.0 3.9 3.9 3.9 3.9 3.9 3.9
-21.8 -22.0 4.8 4.8 4.7 4.7 4.7 4.7
-19.8 -20.0 5.0 5.0 5.0 5.0 5.0 4.9
-18.8 -19.0 5.1 5.1 5.1 5.1 5.1 5.1
-16.7 -17.0 5.4 5.4 5.4 5.3 5.3 5.3
-14.7 -15.0 5.6 5.6 5.6 5.6 5.6 5.6
-12.6 -13.0 5.9 5.9 5.9 5.9 5.8 5.8
-10.5 -11.0 6.1 6.1 6.1 6.1 6.1 5.9
-9.5 -10.0 6.3 6.3 6.2 6.2 6.2 5.9
-8.5 -9.1 6.4 6.4 6.4 6.4 6.4 5.9
-7.0 -7.6 6.6 6.5 6.5 6.5 6.4 5.9
-5.0 -5.6 6.8 6.8 6.8 6.6 6.4 5.9
-3.0 -3.7 7.1 7.0 6.8 6.6 6.4 5.9
0.0 -0.7 7.3 7.0 6.8 6.6 6.4 5.9
3.0 2.2 7.5 7.2 6.8 6.6 6.4 5.9
5.0 4.1 7.6 7.2 6.8 6.6 6.4 5.9
7.0 6.0 7.7 7.2 6.8 6.6 6.4 5.9
9.0 7.9 7.7 7.2 6.8 6.6 6.4 5.9
11.0 9.8 7.7 7.2 6.8 6.6 6.4 5.9
13.0 11.8 7.7 7.2 6.8 6.6 6.4 5.9
15.0 13.7 7.7 7.2 6.8 6.6 6.4 5.9
-24.8 -25.0 4.6 4.6 4.6 4.6 4.6 4.6
-21.8 -22.0 5.6 5.6 5.6 5.6 5.6 5.5
-19.8 -20.0 5.9 5.9 5.9 5.9 5.9 5.8
-18.8 -19.0 6.0 6.0 6.0 6.0 6.0 6.0
-16.7 -17.0 6.3 6.3 6.3 6.3 6.3 6.3
-14.7 -15.0 6.6 6.6 6.6 6.6 6.6 6.6
-12.6 -13.0 6.9 6.9 6.9 6.9 6.9 6.9
-10.5 -11.0 7.2 7.2 7.2 7.2 7.2 7.0
-9.5 -10.0 7.4 7.4 7.3 7.3 7.3 7.0
-8.5 -9.1 7.5 7.5 7.5 7.5 7.5 7.0
-7.0 -7.6 7.7 7.7 7.7 7.7 7.5 7.0
-5.0 -5.6 8.0 8.0 8.0 7.7 7.5 7.0
-3.0 -3.7 8.4 8.2 8.0 7.7 7.5 7.0
0.0 -0.7 8.6 8.3 8.0 7.7 7.5 7.0
3.0 2.2 8.8 8.5 8.0 7.7 7.5 7.0
5.0 4.1 8.9 8.5 8.0 7.7 7.5 7.0
7.0 6.0 9.0 8.5 8.0 7.7 7.5 7.0
9.0 7.9 9.0 8.5 8.0 7.7 7.5 7.0
11.0 9.8 9.0 8.5 8.0 7.7 7.5 7.0
13.0 11.8 9.0 8.5 8.0 7.7 7.5 7.0
15.0 13.7 9.0 8.5 8.0 7.7 7.5 7.0
-24.8 -25.0 5.3 5.3 5.3 5.3 5.3 5.3
-21.8 -22.0 6.4 6.4 6.4 6.4 6.4 6.4
-19.8 -20.0 6.8 6.8 6.7 6.7 6.7 6.7
-18.8 -19.0 6.9 6.9 6.9 6.9 6.9 6.9
-16.7 -17.0 7.2 6.9 7.2 7.2 7.2 7.2
-14.7 -15.0 7.6 6.9 7.6 7.6 7.6 7.5
-12.6 -13.0 8.0 6.9 7.9 7.9 7.9 7.9
-10.5 -11.0 8.3 6.9 8.3 8.3 8.3 8.0
-9.5 -10.0 8.5 6.9 8.4 8.4 8.4 8.0
-8.5 -9.1 8.6 6.9 8.6 8.6 8.6 8.0
-7.0 -7.6 8.9 6.9 8.9 8.8 8.6 8.0
-5.0 -5.6 9.2 6.9 9.2 8.9 8.6 8.0
-3.0 -3.7 9.7 6.9 9.2 8.9 8.6 8.0
0.0 -0.7 9.8 6.9 9.2 8.9 8.6 8.0
3.0 2.2 10.1 6.9 9.2 8.9 8.6 8.0
5.0 4.1 10.3 6.9 9.2 8.9 8.6 8.0
7.0 6.0 10.4 6.9 9.2 8.9 8.6 8.0
9.0 7.9 10.4 6.9 9.2 8.9 8.6 8.0
11.0 9.8 10.4 6.9 9.2 8.9 8.6 8.0
13.0 11.8 10.4 6.9 9.2 8.9 8.6 8.0
15.0 13.7 10.4 6.9 9.2 8.9 8.6 8.0
6.2
7.1
8.2
6. Capacity Tables
