LG MULTI V ARNU12GTRA4

Indoor unit
Ceiling Cassette 4-way _ 23
Indoor Units
6. Capacity Tables
Heating capacity
Notes:
TC: Total Capacity(kW)
1. Capacity tables show the representative value of conditions which may occur.
2. is shown as reference. When selecting the outdoor units, avoid the out-
door air temperature range shown by .
3. In accordance with operation limits of outdoor unit, applicable range of capac-
ity tables is different.
4. Refer to Capacity Correction Factorin the outdoor unit PDBfor the actual per-
formance data of each indoor unitand outdoor unit combination.
Capacity
Index
Outdoor air
temp.
DB(°C) WB(°C)
Indoor air temp. (DB, °C)
16 18 20 21 22 24
TC TC TC TC TC TC
kW kW kW kW kW kW
-24.8 -25.0 5.8 5.8 5.8 5.8 5.8 5.7
-21.8 -22.0 7.0 7.0 7.0 7.0 7.0 6.9
-19.8 -20.0 7.4 7.4 7.3 7.3 7.3 7.3
-18.8 -19.0 7.5 7.5 7.5 7.5 7.5 7.5
-16.7 -17.0 7.9 7.9 7.9 7.8 7.8 7.8
-14.7 -15.0 8.3 8.3 8.2 8.2 8.2 8.2
-12.6 -13.0 8.7 8.6 8.6 8.6 8.6 8.6
-10.5 -11.0 9.0 9.0 9.0 9.0 9.0 8.7
-9.5 -10.0 9.2 9.2 9.2 9.2 9.2 8.7
-8.5 -9.1 9.4 9.4 9.3 9.3 9.3 8.7
-7.0 -7.6 9.7 9.6 9.6 9.6 9.4 8.7
-5.0 -5.6 10.0 10.0 10.0 9.7 9.4 8.7
-3.0 -3.7 10.5 10.3 10.0 9.7 9.4 8.7
0.0 -0.7 10.7 10.3 10.0 9.7 9.4 8.7
3.0 2.2 11.0 10.6 10.0 9.7 9.4 8.7
5.0 4.1 11.2 10.6 10.0 9.7 9.4 8.7
7.0 6.0 11.3 10.6 10.0 9.7 9.4 8.7
9.0 7.9 11.3 10.6 10.0 9.7 9.4 8.7
11.0 9.8 11.3 10.6 10.0 9.7 9.4 8.7
13.0 11.8 11.3 10.6 10.0 9.7 9.4 8.7
15.0 13.7 11.3 10.6 10.0 9.7 9.4 8.7
-24.8 -25.0 6.9 6.9 6.8 6.8 6.8 6.8
-21.8 -22.0 8.3 8.3 8.3 8.3 8.3 8.2
-19.8 -20.0 8.8 8.8 8.7 8.7 8.7 8.6
-18.8 -19.0 9.0 8.9 8.9 8.9 8.9 8.9
-16.7 -17.0 9.4 9.4 9.4 9.3 9.3 9.3
-14.7 -15.0 9.9 9.9 9.8 9.8 9.8 9.8
-12.6 -13.0 10.3 10.3 10.3 10.3 10.2 10.2
-10.5 -11.0 10.8 10.8 10.7 10.7 10.7 10.4
-9.5 -10.0 11.0 11.0 10.9 10.9 10.9 10.4
-8.5 -9.1 11.2 11.2 11.1 11.1 11.1 10.4
-7.0 -7.6 11.5 11.5 11.5 11.4 11.1 10.4
-5.0 -5.6 12.0 11.9 11.9 11.5 11.1 10.4
-3.0 -3.7 12.5 12.2 11.9 11.5 11.1 10.4
0.0 -0.7 12.7 12.3 11.9 11.5 11.1 10.4
3.0 2.2 13.1 12.7 11.9 11.5 11.1 10.4
5.0 4.1 13.3 12.7 11.9 11.5 11.1 10.4
7.0 6.0 13.4 12.7 11.9 11.5 11.1 10.4
9.0 7.9 13.4 12.7 11.9 11.5 11.1 10.4
11.0 9.8 13.4 12.7 11.9 11.5 11.1 10.4
13.0 11.8 13.4 12.7 11.9 11.5 11.1 10.4
15.0 13.7 13.4 12.7 11.9 11.5 11.1 10.4
-24.8 -25.0 8.0 8.0 7.9 7.9 7.9 7.9
-21.8 -22.0 9.7 9.7 9.6 9.6 9.6 9.5
-19.8 -20.0 10.2 10.2 10.1 10.1 10.1 10.0
-18.8 -19.0 10.4 10.3 10.3 10.3 10.3 10.3
-16.7 -17.0 10.9 10.9 10.9 10.8 10.8 10.8
-14.7 -15.0 11.4 11.4 11.4 11.4 11.4 11.3
-12.6 -13.0 12.0 11.9 11.9 11.9 11.8 11.8
-10.5 -11.0 12.5 12.5 12.4 12.4 12.4 12.0
-9.5 -10.0 12.7 12.7 12.7 12.7 12.7 12.0
-8.5 -9.1 13.0 13.0 12.9 12.9 12.9 12.0
-7.0 -7.6 13.3 13.3 13.3 13.2 12.9 12.0
-5.0 -5.6 13.9 13.8 13.8 13.4 12.9 12.0
-3.0 -3.7 14.5 14.2 13.8 13.4 12.9 12.0
0.0 -0.7 14.8 14.3 13.8 13.4 12.9 12.0
3.0 2.2 15.2 14.7 13.8 13.4 12.9 12.0
5.0 4.1 15.4 14.7 13.8 13.4 12.9 12.0
7.0 6.0 15.6 14.7 13.8 13.4 12.9 12.0
9.0 7.9 15.6 14.7 13.8 13.4 12.9 12.0
11.0 9.8 15.6 14.7 13.8 13.4 12.9 12.0
13.0 11.8 15.6 14.7 13.8 13.4 12.9 12.0
15.0 13.7 15.6 14.7 13.8 13.4 12.9 12.0
9.0
10.6
12.3
