103
INSTALLER SETTING
ENGLISH
CN_CC
It is the function to set the usage of the unit’s CN_CC port.
• Change setting values using [<,>(left/right)] button
Value Description
D/C Automatic
When power is applied to the product, the unit when the contact point
is on in Dry Contact installed state recognizes Dry Contact installation
D/C Not Installed Do not use (install) Dry Contact
D/C Installed Use (install) Dry Contact
102
INSTALLER SETTING
Pump Capacity
It is a function to enable installer to control Pump capacity application model.
• In the installer setting list, select Pump Capacity category, and press [OK] button to move to
the detail screen.
OK
Value Description
100 (Default)
10~100 : %
Change unit: 5
NOTE
CN_CC is the device connected to the unit to recognize and control the external contact
point.
