Switch an Input to the Outputs
Description
Example
●
●●
Explanation: I2 audio and I2 video input ports are switched to O1 output port.
Legend:
<layer> Layer
A Audio layer
O1 output port.
I1...I6 input ports.
ATTENTION! The response of this command does not show if the output is muted. To check the mute
ATTENTION!
Mute Output
Description
Example
●
●
{#01 A}
(1MT01 A)
Explanation: O1 audio port is muted.
ATTENTION! Muting does not change the crosspoint’s state but disables the output itself. This way the
last connection can be easily restored with an unmute command. Switching a muted output does not
unmute the output.
Unmute Output
Description
Example
●
●
Explanation: O1 video port is unmuted.
INFO: Unmuting an output makes the previous connection active as the crosspoint state has not been
changed by the muting command, only the output was disabled.
Lock Output
Description: Lock an output port. Output’s state cannot be changed until unlocking.
Example
●
●
(1LO01 A)
Explanation: O1 audio output port is locked.
Unlock Output
Description: Unlock an output port. The connection on output can be changed.
Example
●
●
Explanation: O1 video output port is unlocked.
INFO: The device issues the above response regardless of the previous state of the output (either it was
locked or unlocked).
