1. Introduction HDMI-3D-OPT series – User's Manual 8

3D and 4K Support
High bandwidth allows extension of resolutions up to 4K and even 3D sources and displays are
supported.
2500m
@1080p
60Hz
Signal Transmission up to 2500 m


Deep Color Support and Conversion
It is possible to transmit the highest quality 36-bit video streams for perfect color reproduction.

The Autoselect feature can sense the port status on the video input ports and select
automatically one of them. Priority number can be set for each input port and the feature allows
to set variuos modes for the automatic input selection (First detect, Last detect, Priority mode).
HDCP-compliant
         
disabled when non-protected content is extended.
Built-in Event Manager


environment, there is no need to invest in additional control solutions, which makes the receiver
the best choice for numerous applications.
Pixel Accurate Reclocking
Each output has a clean, jitter free signal, eliminating signal instability and distortion caused by


USB KVM
Connected USB HID devices (e.g. keyboard, mouse, USB HUB) are extended from transmitter to
receiver thus a computer can be remote controlled.
RS-232
Bi-directional RS-232 Pass-through

through supports any unit that works with standard RS-232.
GPIO Control Port

commands.
Model Comparison of the Transmitters
The available models have different features depending on their design. The following table contains the
most important differences between the models:
Ports
Optical
output
Video ports Audio ports Interface ports
HDMI
input

input
DP
input
HDMI
output


input
Phoenix
input
RS-232 Ethernet GPIO
Serial
comm.
USB

HDMI-3D-OPT-TX210A

- -
   
- - C -
HDMI-3D-OPT-TX210RAK

- -
   
- -
C
PT

SW4-OPT-TX240RAK
        
C
PT
CI

C = Control mode, PT = Pass-through mode, CI = Command injection mode. See more information about
serial interface modes in the Serial Interface section.
Typical Application
Application Diagram - HDMI-3D-OPT-TX210A
Laptop
Projector
5V DC
Power
adaptor
HDMI-3D-OPT-TX210A
PIN: 2.1mm
RS-232
TX RX
LIVE
LASER ACTIVE
FIBER LINK
RS-232
12V 1A DC
HDMI OUT
SC MM
LASER APERTURE
OUTPUT
6 AUDIO2 IN
A
A
A
A
HID
A
O
<=
mW
CLASSIFIED B
A
HDMI-3D-OPT-RX150RA
Audio amplifier
5V DC
Power
adaptor
HDMI
HDMI
RS-232
Analog audio
USB
Single fiber multimode
optical cable up to 2500m




