Lightware MMX6x2-HT200 User Manual

Page 68 / 119 Section 7. LW2 programmers’ reference
7.2.3. View firmware version of the CPU
Description: View the CPU firmware revision.
Format
Example
Command
{f}
→
{f}
Response
(FW:<FW_VER><s>)CrLf
←
(FW:1.0.0b1 r2270)CrLf
Legend: <FW_VER> is the firmware version. It is followed by <s> string which may indicate
special versions. <s>=r indicates standard version.
7.2.4. Connection test
Description: Simple test to see if the connection is established successfully.
Format
Example
Command
{PING}
→
{ping}
Response
(PONG!)CrLf
←
(PONG!)CrLf
7.2.5. View serial number
Description: The device responds its 8-digit serial number.
Format
Example
Command
{s}
→
{s}
Response
(SN:<SERIAL_N>)CrLf
←
(SN:5A003192)CrLf
7.2.6. Compile time
Description: Returns the date, when the microcontroller firmware was compiled.
Format
Example
Command
{CT}
→
{ct}
Response
(Complied: <DATE&TIME>)
CrLf
←
(Compiled: Oct 22 2015 11:27:22)
CrLf
7.2.7. View installed board(s)
Description: Shows the hardware name and revision of the installed boards.
Format
Example
Command
{is}
→
{is}
Response
(SL#●0●<MB_DESC>)CrLf
(SL●END)CrLf
←
←
(SL# 0 MMX6x2-HT220 V11_AAA0)
CrLf
(SL END)CrLf
Explanation: The device reports its motherboard (slot 0).
7.2.8. View firmware for all controllers’
Description: Shows the firmware versions of all installed controllers.
Format
Example
Command
{FC}
→
{fc}
Response
(CF●<DESC>)CrLf
(CF●<DESC>)CrLf
…
(CF END)CrLf
←
←
(CF MMX6x2-HT220 1.0.0b1 r2270)
CrLf
(CF END) CrLf
Explanation: The device has one control panel.
