MMX6x2-HT
User’s Manual
Section 5. Installation and operation Page 37 / 119
5.4. Front panel LCD menu operation
The matrix has an LCD menu and navigation buttons which make the possibility to change
certain settings and display basic information via the front panel.
Navigation
Front panel LCD has 2 lines and 16 characters in each line. The name of the menu item is
always displayed in the first line. If no button is pressed for 5 minutes, LCD returns to its
idle state and Device information is shown.
Toggle between menu items
Move the cursor or step back to the previous menu
Execute changes or enter submenu
Step back to the previous menu; cancel the operation
Display mode / Edit mode
The parameters are displayed in two modes on the LCD as follows:
In Display mode, the value cannot be changed; the ▲ up and ▼ down buttons can be used
to step between the submenu items (e.g. IP address – Subnet mask – Static gateway, etc.).
In Edit mode, the values can be changed with the ▲ up and ▼ down buttons.
Display mode is the default; select the desired parameter and press enter to select Edit
mode.
Idle state (Device information)
If no button is pressed for 5 minutes or the user navigates out from the menu by the escape
and/or the left ◄ button, LCD gets into idle state. Front panel menu displays the following
information in idle state:
Menu structure
¹IP Address: »
æ92.168.000.095
¹IP Address:
æ92.168.000.09½
192.168.0.100
LW3 port:6107
Matrix type and serial number
IP address of the device and LW3 port number
