Chapter 6-7-5. PPPOE Setup
To use ADSL modem，please enter the “ username” and “ password” for dialing the ADSL
modem connection successfully。
Chapter 6-7-6. MAC
Display the MAC address of the DVR.
Chapter 6-8. PTZ Setup
The DVR can control RS-485 PTZ or IP PTZ. Using DVR’s keypad or the remote controller
can access all these cameras. To setup PTZ connection, please follow the following
instructions:
Chapter 6-8-1. PTZ Transport
PTZ Protocol is sent to a remote camera by using RS-485. To enable feature, please set
the PTZ Transport to RS-485.
Chapter 6-8-2. PTZ Model & Baud Rate
If PTZ protocol is transmitted via traditional RS485 wires attached to the DVR. Please
setup baud rate and RS485ID respectively.
One can choose the model of PTZ devices by pressing Left or Right button. The DVR
adopts this PTZ model’s protocol and communicates with the PTZ device. Each PTZ device
can be assigned by its PTZ protocol with different baud rate.
PTZ
