Specification
Models DVR304 DVR308 DVR316
Recording SATA HDD: internal * 1 SATA HDD: internal * 2
Recording mode External alarm / motion detection / schedule / manual
Video source Analog * 4 Analog
Analog * 16
Resolution Full D1: 720 * 576 (PAL) 720*480 (NTSC) / CIF: 320 * 288 (PAL) 320 * 240 (NTSC)
Recording NTSC D1 120 / CIF 120 FPS D1 120 / CIF 240 FPS D1 120 / CIF 480 FPS
Recording PAL D1 100 / CIF 100 FPS D1 100 / CIF 200 FPS D1 100 / CIF 400 FPS
Schedule 7 day * 24 hrs time table, recording mode configurable
USB 2.0 flash disk / HTTP file download / Audio supported
External USB DVD/RW
Playback H.264 AVC video
Speed FR: 2x, 4x, 8x, 16x, 32x, 64x / FF:2x, 4x, 8x, 16x, 32x, 64x
Compression H.264 AVC and JPEG
Video Input Analog cameras
Camera Name 12 characters
Live video
PAL: 100 FPS/Sec
NTSC: 120 FPS/Sec
PAL: 200 FPS/Sec
NTSC: 240 FPS/Sec
PAL: 400 FPS/Sec
NTSC: 480 FPS/Sec
Video Output BNC * 1 BNC * 1 + Spot monitor
VGA output 3D intellectual motion adoptive refinement with vivid image enhancement VGA engine up to 1920 * 1080i
Backlight saving LCD backlight saving mode
Multiplexer Sequence / digital zoom / freeze
Digital zoom ROI for 5X and 9X with PIP
No
Split screen 4, PIP 4, 9 4, 9, 16
Spot monitor No Yes Yes
Management
Reports Full alarm, configuration, and operation reports exporting over HTTP or USB
Authentication User authentication with feature configurable
Recording day Dynamic recording day calculation
Alarm/event DI * 4 and DO * 2 (NO/NC)
DI * 8 and DO* 2 (NO/NC)
Motion Motion grid 30*24 each channel, 8 sensitivities
Event
External alarm, video loss, stop recording, power recovering, motion detection, schedule, logon, HDD format
Email Alarm notification with JPEG attachments
Accessories Remote controller addressable up to 255 DVRs
P/T/Z protocol LILIN MLP2 and Pelco RS-485
Keyboards None PIH-931D keyboard
IR receiver None Extra IR extension connector, up to 200 m
Mouse USB / PS-2, drag-n-drop, right-mouse-click, mouse wheel.
Audio G.711 audio, 0.7Vp-p, 16KHz
Audio In/out RCA 1 in, 1 output RCA 4 in , 1 output
Remote control Yes
Network Direct Internet browser access / multiple users access
Protocols ARP / TCP/IP / UDP / HTTP / SMTP / FTP / DDNS / PPPoE / DynDNS / NTP
Web Live / event log & time search playback / AVI / snapshot
DVR status HTML DVR status
IPScan IPScan supported, easy-to-setup for IP address
Software
BackupManager Multiple DVRs FTP file download and multi-channel playback
Mobile phone iPhone, and Android mobile phone supported
Others
WDT Hardware watchdog timer
DST Daylight saving time
Multilanguage
English, Chinese, Spanish, Danish, Swiss, Norwegian, Arabic, Japanese, Germany,
French, Polish, Portuguese, Simplified Chinese, Vietnam, Italian
CPU/OS 32-bit RISC Processor, ARM926 SoC 336 MHz, Linux 2.6 kernel
Power DC 12V, 4.2A, 48W DC 12V, 5.0A, 60W
Working Env. Temp: 0 ~ +50 / Humidity: 0%~80%℃℃
Dimension 290 mm * 52mm * 260mm
360mm * 60mm * 308mm
Weight 1.5 Kg 3.0 Kg
