Actuator with absolute positioning - Analogue feedback:
I/O specifications:
Input/Output Specification Comments
Description The actuator can be equipped
with electronic circuit that gives an
analogue feedback signal when the
actuator moves.
See connection diagram,
fig. 7, page 23
Brown 12, 24 or 36VDC (+/-)
12V ± 20%
24V ± 10%
36V ± 10%
Under normal conditions:
12V, max. 26A depending on load
24V, max. 13A depending on load
36V, max. 10A depending on load
To extend actuator:
Connect Brown to positive
To retract actuator:
Connect Brown to negative
Blue To extend actuator:
Connect Blue to negative
To retract actuator:
Connect Blue to positive
Red Signal power supply (+)
12-24VDC
Current consumption:
Max. 60mA, also when the
actuator is not running
Black Signal power supply GND (-)
Green Not to be connected
Yellow Not to be connected
Violet Analogue feedback
0-10V (Option B)
0.5-4.5V (Option C)
Tolerances +/- 0.2V
Max. current output: 1mA
Ripple max. 200mV
Transaction delay 100ms
Linear feedback 0.5%
It is recommendable to have
the actuator to activate its limit
switches on a regular basis, to
ensure more precise positioning
White Not to be connected
