Page 44 of 76
Actuator with IC Advanced - with BusLink:
I/O specifications:
Input/Output Specification Comments
Violet Analogue feedback (0-10V):
Configure any high/low
combination between 0-10V
Ripple max. 200mV
Transaction delay 20ms
Linear feedback 0.5%
Max. current output. 1mA
Single Hall output (PNP) Output voltage min. V
IN
- 2V
Max. current output: 12mA
Please be aware that when choos-
ing single hall, feedback position
readout and virtual endstops are
not available in BusLink.
For more information, see fig.
6.1, page 22
Digital output feedback PWM:
Configure any high/low
combination between 0-100%
Output voltage min. V
IN
- 2V
Frequency: 75Hz ± 10Hz as
standard, but this can be
customised.
Duty cycle: Any low/high
combination between 0 and 100
percent.
Open drain source current max.
12mA
Analogue feedback (4-20mA):
Configure any high/low
combination between 4-20mA
Tolerances ± 0.2mA
Transaction delay 20ms
Linear feedback 0.5%
Output: Source
Serial resistance:
12V max. 300 ohm
24V max. 900 ohm
All absolute value feedbacks (0-10V,
PWM and 4-20mA)
Standby power consumption:
12V, 60mA
24V, 45mA
It is recommendable to have
the actuator to activate its limit
switches on a regular basis, to
ensure more precise positioning
White Signal GND For correct wiring of power GND
and Signal GND see page 45
Item numbers for BusLink cables: USB2LIN: USB2LIN05, USB2LIN06 and onwards
