COMBINATION CODE NOS. LA36
1 = 1.5 m power cable (0367046-1500)
2 = 5 m power cable (0367046-5000)
36 0 0 0 0 + 0 0 0 0 0 0 0 0
3 = 0.2 m power cable with AMP connector (0367006)
4 = 1.5 m power and 1,5 signal (0367046-1500+0367049-1500)
5 = 5 m power and 5 m signal (0367046-5000+0367049-5000)
6 = 1.5 m Y-cable, power and signal in one (0367020)
7 = 5 m power Cable + Data cable M12x1 (Bus)
2 = Standard (IP66)
8 = IP66 ATEX / IECEx approved
MOTOR TYPE:
A = 12 V DC with clutch
1 = 12 V DC with dummy clutch (as standard only with IC)
2 = 24 V DC with dummy clutch (as standard only with IC)
STROKE LENGTH:
XXX = mm Acme spindle: 100, 150....999 mm
FEEDBACK:
Standard and IC:
0 = Standard (No feedback)
5 = PWM 10-90%
6 = PWM 20-80%
Only standard:
Only IC:
B = Analogue feedback 0 - 10V D = Bus
C = Analogue feedback 0.5 - 4.5V
2 = Analogue feedback 0-10V
P = Potentiometer 3 = Analogue feedback 0.5-4.5V
K = Single hall 4 = Analogue feedback 4-20 mA
END STOP:
0 = With out limt switches 7 = IC Basic
8 = IC Advanced
2 = With limt switches and end-stop signals
A = Modbus (Special article number only)
B = LINBUS
S = With safety nut - only in push
PISTON ROD EYE:
0 = M20 X 1 female adapter 0361016
1 = ø 12.9 mm hole, for 1/2" pin 0361018-B
2 = ø 12.2 mm hole, for 12 mm pin 0361109-B
3 = M12 X 1.75 male adapter 0361224
4 = M16 X 1.5 male adapter 0361135
5 = ø 12.2 hole with slot (Like LA34) 0361138
A = ø 12.2 hole with slot AISI 304 0361260
B = ø 12.9 hole with slot AISI 304 0361275
C = ø 12 H7 Ball Eye AISI 304 0361350
D = ø 16 H7 Ball Eye AISI 304 0361351
BACK FIXTURE:
0 = M20 X 1 female adapter 0361128
1 = ø 12.9 mm hole, for 1/2" pin 0361129
2 = ø 12.9 mm hole turned 90°, for 1/2" pin 0361129
3 = ø 12.2 mm hole, for 12 mm pin 0361119
4 = ø 12.2 mm hole turned 90°, for 12 mm pin 0361119
5 = M12 X 1.75 male adapter 0361126
6 = M16 X 1.5 male adapter 0361247
7 = ø 12.3 hole with slot (Like LA34) 0361140
8 = ø 12.3 hole with slot ( LA34) turned 90° 0361140
A = ø 12.2 hole with slot AISI 304 0361261
B = ø 12.2 hole with slot AISI 304 turned 90° 0361261
C = ø 12.9 hole with slot AISI 304 0361276
D = ø 12.9 hole with slot AISI 304 turned 90° 0361276
8 mm pitch 12 mm pitch 20 mm pitch
A = Gear ratio 1 : 18 N.A. N.A. 2.600 N 1.700 N
B = Gear ratio 1 : 31 N.A. N.A. 4.500 N N.A.
C = Gear ratio 1 : 46 10.000 N 10.000 N 6.800 N N.A.
F = Gear ratio 1 : 7 N.A. N.A. N.A. 500N
SPINDLE TYPE:
1 = 1-threaded acme spindle (2.5 mm pitch)
2 = 2-threaded acme spindle (8 mm pitch)
3 = 3-threaded acme spindle (12 mm pitch)
5 = 5-threaded acme spindle (20 mm pitch)
A = 2 + adjustable reed limit switches (on outer tube)
C = 3 + adjustable reed limit switches (on outer tube)
E = 5 + adjustable reed limit switches (on outer tube)
Bestillingseksempel UM-41-03-051
When ordering standard stroke length with endstop
1, 2, 3 or 4 the stroke length will be up to 4 mm shorter.
LA36
Ordering example
