• The system does not have to run on one power supply only – it can be supplied with several
power supplies
• It does not matter where the IN/OUT signal is applied. The signals of all actuators can be
connected together
• If an overload occurs, the running of the actuators will be stopped and blocked in that direction,
until an activation in the opposite direction has been made or the system has been powered up
again
• When all actuators are connected, a Master will be chosen. E.g. with 5 actuators in one system
there will be 1 Master and 4 Slaves
• Actuators will be pre-programmed from our production as 2, 3, 4, 5 parallel systems etc.
You will not be able to add or remove actuators to/from the system, since they will always run in
accordance with their programming
• In case one of the actuators are broken, the system will not move; not even after re-powering.
The broken actuator needs to be replaced, before the system can run again. The system will only
run, when it is complete
• If you need to add an additional actuator to the parallel system, please contact your local LINAK
supplier. The system will need to be re-programmed
BusLink is available for Parallel
• BusLink can be used for diagnostics
• Parallel can be connected to BusLink – one at a time!
• Service counter is available with Parallel
• Parallel actuator configurations can be changed through BusLink, but all actuators need the
same configurations!
Download BusLink software here: http://www.linak.com/techline/?id3=2363
For more information and easy set-up of BusLink, please follow this link to view the Quick Guide
for BusLink: http://www.linak.com/techline/?id3=2356
Item numbers for BusLink cables:
USB2LIN: USB2LIN05, USB2LIN06 and onwards
Adaptor cable: 0964826-A
Please note that the BusLink cables must be purchased separately from the actuator!
The parallel system:
