LA36
Ordering example Econ
IC options: IC LINbus Modbus Parallel
LA36 actuator:
� � � �
3 6 0 0 1 0 0 0 A P 0 0 0 0 - 6 0 1 0 0 0 2 8 8 2 1 S 0 0 0
Not used 0
Not used 0
Not used
0
Cable: 0 = None
S = Straight
Y = Y-Cable
X = Special
Plug Type:
C = Flying leads
J = Deutsch (DT)
X = Special
Not used: 0
Install. Dim.: XXXX = mm
Brake:
3 = Brake (push/pull)
Option Position: E = Gear ratio 1:7
F = Gear ratio 1:18
G = Gear ratio 1:31
H = Gear ratio 1:46
Piston Rod Eye: 1 = With slot 4 = Outer thread
2 = Solid
5 = Inner thread
6 = Ball eye
X = Special
Back fixture: 1 = 0 degrees 4 = Outer thread
2 = 90 degrees 5 = Inner thread
6 = Rotated (interval 30° )
X = Special
Colour:
6 = Dark Olivish Grey NCS S7000-N
X = Special
IP:
A = IP66
Motor Type: A = 12VDC. Normal 1 = 12VDC. With dummy clutch
B = 24VDC. Normal 2 = 24VDC. With dummy clutch
C = 36VDC. Normal 3 = 36VDC. With dummy clutch
*Platform: 00 = Standard (None)
03 = IC integrated control
04 = MODBUS
06 = LINBUS
XX = Special
Feedback: 0 = None
A = Hall Potentiometer (only IC)
B = Analogue 0-10V (only standard)
C = Analogue 0.5-4.5V (only standard)
D = MODBUS (only IC)
F = PWM
H = Dual Hall (only Standard)
K = Single Hall
P = Potmeter (only standard)
Z = Hall and potentiometer (only standard and special items)
X = Special
Safety : A = Safety nut
Stroke Length:
XXX = mm.
Spindle Pitch: 080 = 8 mm
120 = 12 mm
200 = 20 mm
Actuator Type:
36 = LA36
H = AMP
