Actuator with endstop signals and absolute positioning - PWM:
I/O specifications:
Input/Output Specification Comments
Description The actuator can be equipped
with electronic circuit that gives an
analogue feedback signal when the
actuator moves.
See connection diagram,
fig. 12, page 33
Brown 12, 24 or 36VDC (+/-)
12V ± 20%
24V ± 10%
36V ± 10%
Under normal conditions:
12V, max. 26A depending on load
24V, max. 13A depending on load
36V, max. 10A depending on load
To extend actuator:
Connect Brown to positive
To retract actuator:
Connect Brown to negative
Blue To extend actuator:
Connect Blue to negative
To retract actuator:
Connect Blue to positive
Red Signal power supply (+)
12-24VDC
Current consumption:
Max. 60mA, also when the
actuator is not running
Black Signal power supply GND (-)
Green Endstop signal out Output voltage min. V
IN
- 2V
Source current max. 100mA
NOT potential free
Yellow Endstop signal in
Violet Digital output feedback (PNP)
10-90% (Option 5)
20-80% (Option 6)
Output voltage min. V
IN
- 2V Tol-
erances +/- 2%
Max. current output: 12mA
Frequency: 75Hz
It is recommendable to have
the actuator to activate its limit
switches on a regular basis, to
ensure more precise positioning
White Not to be connected
PWM
