Linde H30D - Type sheet H 30, as at 05;2008

Technical data 6
Type sheet H 30, as at 05/2008
Type sheet H 30, as at 05/2008
1 Identification
1.1
Manufacturer
Linde
1.2
Manufacturer’s model designation
H30D
1.3 Drive Diesel
1.4
Operation
Seated
1.5
Load capacity / Load
Q [kg]
3000
1.6
Load centre of gravity c[mm]
500
1.8 Load distance
x[mm]
445
1.9 Wheelbase
y[mm]
1930
2 Weight
2.1
Tare weight kg
4220
2.2
Axle weight with front/rear load kg
6420 / 800
2.3
Axle weight without front/rear load kg
1950 / 2270
3 Wheels, chass
is frame
3.1
Front/rear tyres: polyurethane, rubber
SE
3.2
Tyre size, front
27x10-12
11
3.3
Tyre size, rear
23x9-10
12
3.5
Wheels, number, front/rear (x = driven) 2x (4x)/2
13
3.6 Front track width
b10 [mm] 1008 (1204)
14
,
15
3.7
Track width, rear
b11 [mm]
932
4 Basic di
mensions
4.1 Forward/backward fork tilt
α/β (°)
5.0/8.0
16
4.2
Lowered mast height
h1 [mm]
2264
17
4.3 Free lift
h2 [mm]
150
11
Optional: 7.00-12 dual fitment (air/SE). Single tyres air 27x10-12 and SE 28x12.5-15.
12
Optional: air 23x9-10.
13
Bracketed value for dual fitment.
14
1042 mm with tyre size SE 28x12.5–15.
15
Bracketed value for dual fitment.
16
Lift height and equipment can change the backwards tilt.
17
With 150 mm free lift on standard lift mast.
Operating Instructions – 393 807 1001 EN – 08/2008 207
