Linde H30D - Check the Forks and Fork Quick-Releases

Maintenance 5
Load lift system
3
4
d3921486
¾ Loosen locknut (4). Adjust chain at adjust-
ment nut (3) of chain anchor.
The lower guide roller of the fork carriage
should only protrude max. 25 mm from the
guide rail of the inner lift mast.
¾ Tighten the locknut (4).
CAUTION
When extended, the lift mast should not touch the
end stops.
Fully extend lift mast and check clearance to end
stops.
Apply chain spray.
NOTE
In the case of trucks that are used in the food
production sector, chain spray should not be
used. Instead, use a low-viscosity oil licensed
for use in the food industry.
¾ Apply Linde chain spray to guide surfaces
and chain.
Check the forks and fork quick-
releases
d3921451
¾ Check the forks for visible deformations,
wear and damages.
¾ Check the bolts of the fork stops and fork
quick-releases for correct seating and dam-
age.
¾ Replace any defective parts.
Operating Instructions – 393 807 1001 EN – 08/2008 179
