6 Technical data
Load capacity diagrams and lift mast data as at 07/2011
Duplex lift mast (in mm)
H40
2325 2375 2425 2675 2875
H 45/50
2376 2426 2476 2726 2926
Overall heights when
retracted with specified free
lift
h1
H 50/600
-----
H40
1561 1611 1661 1911 2111
H 45/50
1460 1510 1560 1810 2010
Free lift
h2
H 50/600
-----
H 40–50
3030 3130 3230 3730 4130
Lift
h3
H 50/600
-----
H40
3794 3894 3994 4494 4894
H 45/50
3946 4046 4146 4646 5046
Overall height when
extended
h4
H 50/600
-----
Triplex lift mast (in mm)
H40
2325 2375 2625 2825 2975
H 45/50
2376 2426 2676 2876 3026
Overall heights when
retracted with specified free
lift
h1
H 50/600
2376 2426 2676 2876 3026
H40
1564 1614 1864 2064 2214
H 45/50
1460 1510 1760 1960 2110
Free lift
h2
H 50/600
1360 1410 1660 1860 2010
H 40–50
4525 4675 5365 5865 6315
Lift
h3
H 50/600
4225 4375 5065 5565 6015
H40
5286 5436 6126 6626 7076
H 45/50
5441 5591 6281 6781 7231
Overall height when
extended
h4
H 50/600
5241 5391 6081 6581 7031
