LinMot Step - COM Connector

LinMot



Design and Installation
User Manual V1.01 4-17
4.5.3 COM connector
This port serves the connection to the serial interface of a PC for the configuration with
the LinMot

Talk software.
Table 4-3: Pin configuration of the COM connector
A 9-pole interface cable with 1:1 connections is needed for the connection of the
electronic unit to a PC.
Pin Description Pin Description
1 NC 6 NC
2 RS-232 TX 7 NC
3 RS-232 RX 8 NC
4 NC 9 NC
5 GND
