5.8.3 Curve Editor interface
Reference curves can be created in different ways with the help of the “Wizards”. The
input possibilities and the interface are adapted accordingly. The Curve Editor is used to
edit the curves. Depending on the type of curve it can have one of the following
interfaces.
Figure 5-9: Manual creation of curves
Curve definitions Graph Curve points
Edit buttons Close buttons
Graph buttons
