Chapter 9. MIDI
9-1 Introduction of MIDI
“MIDI” is an abbreviation for “Music Instrument Digital Interface”. MIDI interface will carry out a
string of digital code while users play the keyboard.
Basic MIDI format include :
The function “MIDI IN” of CX-5 can call out the 24 data saved in “SCENE” according to the
first two data- 【 CHANNEL 】 and 【 NOTE 】 .
MIDI interface can send out 16 different kinds of musical effect by installing different value on
CHANNEL (1-16). As a result of that, the MIDI-CHANNEL in CX-5 has to be corresponding
to the CHANNEL of MIDI interface, then CX-5 can receive the data which MIDI interface
sends out correctly.
【 NOTE 】 can send 128 different kinds of digital code to CX-5. CX-5 would divide the 128 note
into 24 team of MIDI MEMORY, and each one of that represents a “SCENE”.
【 CHANNEL 】 (For different kind of musical instrument)
【 NOTE 】 (From 0 to 127)
【 VELOCITY 】 (From 0 to 127)
