CX-5 [EUM-B] 38
Chapter 11. Main Lamp Setting
When users enter the function “CHASE”
､
“MACRO”
､
“LEARN”, all the lamps will be
controlled by the program. But if users press “FNC” + “987” and enter the function “MAIN
LAMP SETTING”, they can choose a main lamp “LAMP 1….12” by using
“w -” & “+ 4“.
After the main lamp have selected, the main lamp won’t change the output as the program changes
with running of “CHASE”
､
“MACRO”
､
“LEARN”, but users can change its output and position
by controlling of the joystick controller VR.
11-1 How to setting main lamp
STEP-1 Press “FNC” + “987” .
STEP-2 Use “w -” & “+ 4“. Assign main lamp.
STEP-3 After make sure the MAIN LAMP, press “ENTER“. LAMP 1 will be assigned
"MAIN LAMP"
SELECT MAIN LAMP
