CX-5 [EUM-B] 41
Chapter 13 Appendix
Appendix-1:
How to make a " SCENE "
STEP-1: Press the "SECNE" key to be in the "SCENE MODE" situation.
STEP-2: To make sure the led which is beside "A" function key is "OFF" situation
(Led "OFF" means into "EDIT", the user can control 1…12 intelligent lights through
P1…P12.)
STEP-3: Press any key from P1…P12, and choose the intelligent lights you want to control.)
STEP-4: Push the CH1 VR to the top first, then pull it down to the bottom, and move it to the
right position to change the channel corresponding with the CH1 VR. The data in the
other channels will be unchanged.)
STEP-5: Push the crank handle to right first, then push it to left, and move it to the right position to
change the data of PAN. The data in the other channel will be unchanged.
STEP-6: Push the crank handle to the top first, then pull it down to the bottom, and move it to the
right position to change the data of TILT. The data in the other channels will be
unchanged.)
STEP-7: You can change the data of the channels corresponding with CH1 VR by step1…step6,
the data of the other channels which have not been operated by the steps of pushing VR
will not change with the changed position of VR.
STEP-8: The data of selected intelligent lights can be changed by pushing VR just like the
step4…step6, then you can use "PROG" key to save the output data in "SCENE"
memories.
