CX-5 [EUM-B] 34
Chapter 10.
How to call out pattern built in the program
10-1 Explanation of the pattern built in the program
(1) There are 3 different pattern (circle. Vertical. line. horizontal line) and four pattern combinations
(V2.X edition) built in CX-5.
(2) Users can preview pattern built in the program by press “FNC” + “984”.
(3) In the function “Preview Of Pattern Built In The Program”, users can select 4 different kinds of
pattern combinations by keying in number “1~4”.
(4) After the pattern has been decided, users can move the control stick whose location represents
the center of the pattern.
(5) Users can change the radius of the movement of the pattern by move “MASTER”.
(6) Users can change the speed of the movement of the pattern by move “CHASS SPEED VR”.
(7) Table of 4 pattern combination
PATTERN 1 PATTERN 2 PATTERN 3 PATTERN 4
LAMP 1 Circle vertical line horizontal line circle
LAMP 2 Circle vertical line horizontal line vertical line
LAMP 3 Circle vertical line horizontal line horizontal line
LAMP 4 Circle vertical line horizontal line circle
LAMP 5 Circle vertical line horizontal line vertical line
LAMP 6 Circle vertical line horizontal line horizontal line
LAMP 7 Circle vertical line horizontal line circle
LAMP 8 Circle vertical line horizontal line vertical line
LAMP 9 Circle vertical line horizontal line horizontal line
LAMP 10 Circle vertical line horizontal line circle
LAMP 11 Circle vertical line horizontal line vertical line
LAMP 12 Circle vertical line horizontal line horizontal line
(8) The 12 lamps must be the same type and manufactured by the same manufacturer when
running the above function.
