CX-5 [EUM-B] 42
Appendix-2:
Call out the saved scene to amend any of the channels.
STEP-1: Press the "SCENE" key to be in the " SCENE MODE ".
Set the channels of 1…12 intelligent lights as follows:
CH1 VR = COLOR
CH2 VR = GOBO
STEP-2: Press the SCENE NO.(range 1…300) via digital "0…9", then press
"ENTER" to call out the scene you want.
Example: the data of the called scene is:
Intelligent light 1 the red round.
Intelligent light 2 the red round.
Intelligent light 3 the red round.
STEP-3: Press P1, P2, P3 to light their leds.
STEP-4: Push CH1 VR to choose the color you want. If you want to change round
to other shapes, please push CH2 VR.
STEP-5: Use "PROG" key to save the output data in "SCENE" memories.
Appendix-3:
Something important you have to know
when you use P1…P12 to choose the light you want to control.
After pressing P1…P12 to choose the intelligent lights you want to control, you must repush the VR
up and down to change its data.
