Chapter 1. The main function of CX-5
1-1 The features of CX-5
l Easy operation:
There is a “LED” indicator beside every function key for reminding users to know to
current condition and for following operation.
l Compatibility:
CX-5 can control any kind of lighting fixtures and has a data bank of more than
100 famous fixtures inside.
l 1M byte memory, for storing the following data:
<1>. SCENE : 306 sets of “SCENE” memory .
Each set of “SCENE” has independent Xfader SPEED (Time for one
scene to next one) and Chase SPEED (Time for one scene to next one
plus delay time) time for setting .
Each “SCENE” is namable by 10 characters.
6 built in “SCENE” from 301 to 306.
<2>. CHASE : 50 sets “CHASE” memory .
Each set of “CHASE” has 60 STEP , each CHASE STEP means a
“SCENE” memory.
Each CHASE STEP allow to defined both the Xfader SPEED and
Chase SPEED .
Each “CHASE” is namable by 10 characters.
<3>. MACRO : 50 sets of “MACRO” memory .
Each set of “MACRO” has 60 STEP , each
MACRO STEP can be a set of “SCENE”
memory of a set of “CHASE” memory.
Each “MACRO” is namable by 10 characters.
<4>. LEARN : 50 sets of “LEARN” memory .
Each set of “LEARN” memory is corresponding to any set of
NOTE: Please make sure the protocol of your scanner is DMX signal,
8 bit and not over 14 channel first.
