CX-5 [EUM-B] 40
“FNC” + “987” → Set up MAIN LAMP of CX-5 (please refer to Chapter 11).
Users can select one of “MAIN LAMP 1…12” as MAIN LAMP or
“MAIN LAMP OFF” by pressing “w - ” & ” + 4“.
“FNC” + ”988” → For user define the channel of Pan and Tile.
“FNC” + ”989” → For selecting “chase control by program” or Manual override.
STEP-1 : Press “FNC”+”989”
STEP-2 : Press ”ENTER”, it means chase controlled by program.
STEP-3 : If you want manual override, use “w-“ or “ +4” to
select
“FNC “ + “971 “ → For Chase Steps Preview. Select the chase you want to preview and
press ”GO” to go to next step.
“FNC “ + “972 “ → For selecting the moving speed under CHASE mode. It can be
controlled by program or user.
STEP-1 : Press"FNC" + "972"
STEP-2 : Press “ENTER”, user can control chase time by adjusting VR.
STEP-3 : If you want it be controlled by program, use “w-“ or “+4” to
select
STEP-4 : Press “ENTER” to confirm.
CHASE CONTROLER
