CHAPTER 1: BASIC NOTIONS 9
TRYTON 107/112
5.2. Layout of the safety elements
Designation Description
A Main access cover
B Emergency Stop push button
SQ10
Safety switch for loading arm
(option, not represented in this picture)
SQ11 Safety switch for main access cover
B
SQ11
A
SQ10
