28 CHAPTER 4: ELECTRICS
TRYTON 107/112
1. ELECTRICAL EQUIPMENT
Please read the safety precautions described at the beginning of this manual before
handling the following devices.
Particular attention should be given to the handling of electrical elements because of risks
of electrocution. In case of possible electrical malfunctions, it is advisable to contact LNS
or their local representative.
It is strictly prohibited to make adjustments as long as the bar feed system is under electrical
power. The adjustments of the electrical equipment must only be performed by qualified
personnel.
1.1. Description
The electrical parts of the bar feed system, as well as the diagrams representing them, conform to the
ISO/IEC 204-1, 617 international electrical codes.
This chapter contains all of the elements regarding the electrical circuit of the bar feed system. The electrical
parts, and groups, which may require a setting, at some time or other, are described herein in detail.
Whenever possible, the article numbers of the elements are shown in tables below each
drawing.
