4. LAYOUT OF THE ELEMENTS
Designation Description
A
Connector / Feeding pusher
B
Movable vise
C
Material presence monitor
D
Barrel
E
Barrel lock
F
Remote control
G
Main access cover
H
Front foot
I
Rear foot
J
Hydraulic tank
K
Indexing motor
L
Air filtering unit
M
Pneumatic / electrical cabinet
N
Connector feed motor
O
Cable feed motor
P Material support
Q
Back stop
R Front stop
S
Stationary control
T
Loading arm (option, not represented)
A
G
B
C
D
E
F
H
I
K
M
N
O
Q
S
T
J
L
P
R
