64
2 Description
2.6 Menu types
Push the relevant keys to open a menu.
While the red ring on the Selector / Confirm button is illuminated, the button can be turned or
pressed to
– change settings such as dispense time,
– scroll within a menu, but also to
– store the selected value.
Within the On/Off menu, the channel keys for dispense channels A and B are defined as
switches.
Within the channel setup menu, the channel keys for dispense channels A and B are assigned as
scroll keys, as the button is required for setup of time values. Channel key A scrolls upward,
channel key B downward.
In case of a wrong input, abort the procedure by pushing key ESC/Lock and start again.
2.6.1 On / Off menus
This description applies to the following menus:
– "Dispense channel setup" with preselection of the dispense channel
– "Dispense channel setup" without preselection of the dispense channel
– "Online Flow Monitor" without preselection of the dispense channel (for reference dispensing
cycles)
"Setup mode" with preselection of the dispense channel
2.6.2 Selection menus
This description applies to the following menus:
"Preselection of stored dispense programs"
"System setup"
2.6.3 Value setup menus
This description applies to the following menus:
– "Online Flow Monitor" with preselection of the dispense channel
– "Dispense, pre-delay and post-delay times, DC motor speed" with preselection of dispense
channels A or B.
– "Dispense, pre-delay and post-delay times, DC motor speed" without preselection of dispense
channels, channel A automatically selected
2.7 Peripheral connection options using valve modules
Various dispense valves and accessories can be connected to the controller. They all require a
pneumatic and/or electrical connection. For this purpose, pneumatic (internal valve module) and
electrical connections are provided on the rear panel of the unit. Whenever an external solenoid
valve module is used, all required dispense system components are connected to this module. It is
not possible to control components connected both to the internal and the external valve
module.
