Loctite 97152 - Annex: Peripheral Module Wiring; External Valve, Rotor, and Proximity Switch Connections

92
7 Annex
7.2.8 XS 12 External solenoid valve module
7.2.9 XS 16 Rotor unit
7.2.10 XS 17 / XS 18 Proximity switch advancing slide
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
+24VDC
+0VDC
Start Rotor C
Start Rotor D
Analogue/IN
Adv. Slide C in front
Analogue/IN
Adv. Slide D in front
Analogue/IN
Analogue/IN
Adv. Slide D back
Analogue/IN
Adv. Slide C back
Controller
Solenoid Modul
Dispense Valve C
Dispense Valve D
Adv. Slide C in front
Dispensing Valve C
Dispensing Valve D
Advancing Slide C
Advancing Slide D
Adv. Slide D in front
1
1
1
0
0
0
1
0
1
2
3
4
1
2
3
4
Controller
1
2
+ 24VDC
0 VDC
Start
LED on
= Speed o.k.
I/O Signal
M
+ 24VDC
max. 50 mA
1
2
3
4
1
2
3
4
Controller
+ 24VDC
+ 24VDC
Out X
0 VDC
brown
black
blue
X/IN
Proximity Switch
Festo, SME-8-K-LED-24
