3 Technical Data
3.1 Electrics
Power supply 100-240 VAC; 50/60 Hz
Power consumption approx. 60 W
Power fuse Glass tube miniature fuse, 2A semi time-lag
Internal control voltages 5 VDC; 24 VDC
Protection IP 33 acc. to VDE 0470, Part 1 / EN 60529-1991
3.2 Pneumatics
Pneumatic supply min. 2 bar; max. 10 bar
Observe technical data specified for the dispense
valve!
Quality
If the required quality is not achieved,
install a Loctite
®
97120 filter regulator.
filtered 10 µm, oil-free, non-condensing
Order No. 88649
Adjustment range of the pressure
regulator
0.1 – 7.00 bar
Pressure indication 0.1 – 7.00 bar
Pressure range of optional external
solenoid valve module 97204
2.5 – 8 bar
Pneumatic hose size, P in ID Ø 4 mm ; OD Ø 6 mm
Pneumatic hose size, to connect reservoir ID Ø 4 mm; OD Ø 6 mm
OD Ø ¼ inch (6.3 mm) not suitable!
Pneumatic hose size, to connect dispense
valves
ID Ø 2.5 mm ; OD Ø 4 mm
Pneumatic hose size, to connect
advancing slides
ID Ø 2.5mm; OD Ø 4 mm
3.3 Dimensions and other data
Dimensions W x H x D: 150 x 230 x 270 mm
Operating temperature +10 °C to +40 °C
Storage temperature -10 °C to +60 °C
Weight 3.0 kg
