Loctite 97152 - Annex: XS 10 PLC and XS 11 DC Drive Wiring; PLC External Power Supply and DC Drive Connections

91
7 Annex
7.2.6.2 XS 10 PLC external power supply
7.2.7 XS 11 DC drive
1
2
3
1
2
3
4
5
6
7
8
9
4
5
6
7
8
9
10
11
12
13
14
15
10
11
12
13
14
15
1
2
1
2
1
2
1
2
+0VDC
+24VDC
Ready Channel A
Ready Channel B
Error Channel A
Error Channel B
Start Channel A
Start Channel B
Pot. 24V
Tank Refill
Tank Emtpy
Pot. 0V
Controller PLC
Reset Channel A
Reset Channel B
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Controller DC Drive
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Dir
Ena
Brk
Tacho A
Drive enable
+ 24 VDC
Speed A out (0-10V)
Speed B out (0-10V)
GND
Tx 2
Rx 2
RS232 Interface
Caution!
TTL Signals! 5V!
Interface only for the use with LOCTITE drives!
