1 Please observe the following
While under warranty, the unit may be repaired by an authorized Henkel service representative
only.
Danger!
The manufacturer cannot be held responsible for damage or injury of any kind because of misuse
or improper application or because of failure to observe safety instructions or warnings.
It is the responsibility of the user to ensure that all devices actuated by the controller are
positioned in a safe manner.
Do not remove, by-pass or disable any safety device! This can result in damage to the unit and is
therefore prohibited!
Always wear goggles when working with compressed air!
Disconnect power supply before opening the housing!
Check the power cord and the unit before each use. Damage to the power cord or the housing can
result in contact with live electrical parts.
Replace a damaged power cord immediately.
1.4 Field of application (Intended Use)
The Dual Channel Controller 97152 is a versatile multi-functional controller for actuating 1 – 2
dispensing valves as well as appropriate peripheral equipment such as reservoir, advancing slides,
rotor sprays, on-line flow monitors, etc.
The processes and the data for all channels are displayed clearly and concisely. Settings can be
made intuitively via the keyboard and the user interface.
For easier adjustment of the on-line flow monitor, the measured values are graphically displayed.
The amount of product dispensed is controlled by the amount of pressure in the reservoir and the
length of time the dispensing valve remains open, unless a volumetric dispensing system is used.
The controller can be integrated into fully automated assembly line operations by means of the
integrated PLC interface. Therefore the primary controller is liberated from additional, time-
critical tasks related to dispensing control and monitoring. It is possible to query data records via
a PC interface for documentation, maintenance or quality assurance.
The controller is equipped with an integrated pneumatic solenoid valve module. Connecting an
external module is also an option.
