66
2 Description
2.7.3
External pneumatic/electric solenoid valve module: 2 dispense
channels
All components must be connected to the external solenoid valve module. Connecting
components to a mixed configuration of internal and external valve modules is not possible.
Flow monitors are connected to connection XS 3. Use splitter cable 97529 for connecting two
pressure based on-line preamplifiers.
The product reservoir is connected to connection XS 2.
Dispense channels A/B, each
Connectable components LOCTITE designations
1 dispense valve with double acting actuator
(for dispense valves with single acting
actuator, close port 0 with blind plug).
– Diaphragm Valve 97135 or 97136
– Stationary Applicator Valve 97113 or 97114
– Cyanoacrylate Dispense Valve 97134 or 98013
– Light Cure Dispense Valve 98009
1 double acting advancing slide – Advance Slide 97118 or 97119
1 electric rotor unit – Rotospray 97115 or 97144
1 Flow monitor
– Pressure based On-line Pre-amplifier
97211and dispense valve with pressure sensor,
or
– Calorimetric Pre-amplifier 97512 with
dispense valve 97830
1 DC motor
– Eccentric Rotor Pumps 97660, 97663, 97665
or 97669
For both dispense channels
Connectable components LOCTITE designations
1 Product reservoir – 0.5 l product reservoir 97125 or 97106
– 2 l product reservoir 97108
– Supply Pump 97809
– 2 l Bag Dispenser 97124
Both dispense valves must be supplied from one product reservoir as the controller will handle
only one reservoir low level sensing function. Whenever supplying a second dispense valve from
the reservoir, replace the reservoir lid with a lid with 4-way splitter 8953094 for the 0.5 l
reservoir. Use 4-way splitter 8953095 for the 2l reservoir.
