Lorex L222A8 Series User Manual

Technical Specifications20
20.1 Wire-Free Recorder (L222A8 Series)
20.1.1 System
Operating System Embedded Linux
Number of Channels 8 Channels
20.1.2 Inputs/Outputs
VGA OUT No
HDMI Yes
Video Output Resolution 1920×1080, 1440×900, 1280×1024, 1280×720,
1024×768
Ethernet 8P8C 10/100 Base-T
USB Port 3 in rear (Mouse, Backup, USB Storage)
20.1.3 Playback & Display
Display Split 1/4/6/8
Frame Rate Max 20 fps (single camera) @2MP/Channel
Max 100 fps Total @2MP/Channel
OSD Yes
Control USB mouse / Lorex Cirrus App
Firmware Upgrade Network / USB device
Playback Functions Play, Pause, Stop, Fast Forward/Backward (2x, 4x,
8x); Slow Forward (½×, ¼×, ⅛×); Step Forward/
Backward
20.1.4 Recording
Video Compression H.264 / H.265+
Recording Resolution 1920 × 1080 (FHD)
Event Type Motion Detection / Person Detection
Modes Motion Only (default setting) / Continuous (requires
HDD & continuous power from outlet to cameras)
Post-event 0 min / ½ min / 1 min / 2 min / 5 min
20.1.5 Storage & Archive
External microSD Class 10 or Higher (Up to 256 GB)
Internal HDD 2.5" SATA HDD (Up to 1 TB) non-upgradable
Backup Media USB flash drive, HDD & network
Backup File Format LF / MP4
20.1.6 Connectivity
Remote App Clients Web, iOS®, Android™, iPadOS®
Voice Assistance Google Assistant
Protocol Support TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP,
HTTP, DHCP, SMTP, DNS, DDNS
20.1.7 General
Housing Material Plastic
Input Voltage 12 VDC
#LX400115; r. 3.0/57178/57178; en-US 78
