Operation
Operation 3-
5
4. Fuel inspection and replenishment
Note:
* Be sure to stop the engine while r efueling.
* Please never go near fireworks.
▶ If you are negligent ……
Could cause a fire.
Please check with oil gauge. The oil gauge operates when the starting key is in the "RUN" position.
When fuel is low, open the fuel tank cover to refill.
IMPORTANT
After the operation, please fill up the fuel tank and tighten the fu el tank cover.
There is an oil gauge next to the fuel port. When the fuel tank is nearly full, the needle of the o il
gauge will swing to show th e amount of oil.
Be sure to use the fuel tank screen when refueling.
Please pay full attention to the fuel tank to avoid mixing with dirt or moisture.
As long as there is oil in the fuel tank, there is usually no air coming into the fuel system. If air is
mixed, exhaust. (The method of exhaust is described in the section "ex haust of fuel system" in
maintenance.)
There is an air hole in the fue l tank cover, which will cause negative pressure to form i n the fuel tank
if it is blocked by dirt, etc. Therefore, please cl ean up when refueling.
After refueling, please close t he fuel tank cover and lock it with the k ey.
5. Check and replenish oil
Please check if the specified amount o f oil
is loaded.
It is normal if the oil content measured by
the oil gauge is within the range shown in
the figure.
If fu el is low, remove the lower left cover
of the driver and refill from the refueling
port. (Plea se refer t o "recommended
lubricating oils" section)
Fuel meter
Vent
Fuel tank cap Oil standard
Fuel tank cap
If it is in this range,
it is appropriate.
Oil standard
