34
LCX-112C and LCX-113C HD Cable connections.
Display unit,
rear view
GPS
antenna
module
Power/Data
socket
Extension
cables
NMEA 2000
power cable
Sona
socket
Transducer
Network
socket
Optional
speed
sensor
120-ohm
terminator
NMEA 0183
data cable
Ethernet
socket (for
future use)
Display unit
power cable
Double T
connector
terminator
