69
FlashGraf™
The FlashGraf sonar page option represents the flasher style sonar
combined with a scrolling chart. A circular dial shows all returning echoes at
a high screen refresh rate. It uses the Colorline®
feature to show weaker
targets as darker colors. The bottom depth is shown as a black bar across
the outer circle.
You can adjust the size of the chart and the flasher windows by using
the Resize Window command, found on page 109.
FlashGraf page.
Map With Sonar Split Screen
There is a page mode that splits the screen in half, with the map on the
left and the sonar on the right. This screen option can be found on the
Pages Menu under the Map Page category.
Map with Sonar split screen.
Bottom signal
Surface
clutter
Fish signal,
approximately
27 feet
