LCX-27C and LCX-28C HD Cable connections
Power/Data
socket
Display unit,
rear view
Sonar socket
Network socket
Optional
speed
sensor
Extension
cables
120-ohm
terminator
GPS
antenna
module
Transduce
r
NMEA 2000
Power Cable
NMEA 0183
Data Cable
Ethernet
socket (for
future use)
terminator
Double T
connector
Display unit
power cable
