Tachometer
The tachometer shows the engine revolutions
per minute (“30” means 3000rpm). The display
will return to zero when the engine is not running
2
Turn signal indicator (Left / Right)
When turning the turn signal light switch to the
left/right direction, the front/rear turn signal lights
and this indicator will blink simultaneously. The
key switch has to be in the “ON” or “Start”
positions. Before turning the vehicle while driving
on the road, turn on the turn signal lights.
When turning on the hazard warning light switch,
all the turn signal light will blink simultaneously
regardless of the key switch position. Use the
hazard warning light switch in an emergency
state according to your local traffic regulation.
3
Parking brake indicator
This indicator will be turned on when applying the parking brake. Do not drive the vehicle with the
parking brake applied.
If shifting the F/R shuttle lever forward or reverse when the parking brake is engaged, this indicator
will blink with alarming buzzer.
4
High beam indicator
When turning on the high beam of the headlamps, this indicator will be turned on simultaneously. Do
not turn on the high beam when a vehicle comes in the opposite lane.
5
Brake pedals not latched indicator (Not used)
6
Hydraulic oil filter pressure indicator
7
Differential lock indicator
This indicator will be turned on when activating the differential lock switch with the key switch placed
“ON” position. .
2
3
5
6
1
4
If the pressure differential of the hydraulic oil filter is increased over the designated level, this
indicator will be turned on. Replace the oil filter with a new one.
It may be turned on in cold winter. Warm up the transmission oil and recheck the indicator.
When the brake pedals are not connected with brake pedal latch, the LH/RH pedal is can be
operated separately, and this indicator will be turned on. (optional)
7
