Chapter 3 Installation and Operation
3-9
2) Steps of operation
The steps will be described below, starting from installation complete on PLC to test operation
Start
Power on:
1)
Confirm input power.
2)
Check communication cable connection.
3)
Power on.
4)
Check if power LED of power module is turned on.
5)
Check LED status of CPU module.
->
If abnormal, refer to Troubleshooting in user manual of each PLC model.
6)
Check if LED status of communication module is normal or not.
->
If abnormal, refer to Chapter 10. Troubleshooting in this user manual.
7)
Set system parameters correctly so to download.
▼
Programming: Program execution program with XG5000 and write to CPU module.
▼
Sequence check :
Confirm the operation of communication module according to program.
▼
Program modification :
If abnormal in sequence program, let it modified.
▼
Program preservation :
1)
Save the program onto floppy or hard disk.
2)
Print circuit drawings and list.
3) Save the program in the memory module when it is necessary.
End
