6 Main Display
The normal mode of operation is to display the sensor reading on the top row and
a secondary reading on the bottom row. Using the “UP” and “DOWN” keys the
user can cycle through the secondary parameters (those available depend upon
the instrument options and configuration).
10.00
10.0010.00
10.00
ppm
Sat. : 100.0%
Sensor Concentration + Saturation
(When Display units are Concentration)
Ø
ØØ
Ø ×
××
×
100.0
100.0100.0
100.0
%
Conc. : 15.53 ppm
Sensor Saturation + Concentration
(When Display units are Saturation)
Ø
ØØ
Ø ×
××
×
Any combination of Sensor operating units can be displayed here in the same
format as the two examples above, but are excluded here for brevity (a total of
20 combinations are possible). The main display will always be the units
selected in the Parameters Menu (%Sat, ppm, mBar, mm Hg, nA/uA). The
secondary display can be one of the remaining four units or as follows below.
Ø
ØØ
Ø ×
××
×
60.0
60.0 60.0
60.0
%
SP1 : 10.0%
Sensor + Set Point 1
(When SP1 Trigger = High or Low)
Ø
ØØ
Ø ×
××
×
60.0
60.0 60.0
60.0
%
SP1H : 4.00%
Sensor + Set Point 1 High
(When SP1 Trigger = Band or Latch)
Ø
ØØ
Ø ×
××
×
Continued on next page .........
