Appendix F – Temperature Sensor Data
97
Appendix F – Temperature Sensor Data
The table below lists approximate resistance values of temperature sensors that
may be used with the MXD53 series. Not all options are available on all models.
Temperature
(°
°°
°C)
PT1000
RTD**
LTH 1K
Thermistor
BJ 22K
Thermistor
0
1000.0Ω 2691Ω 64.88 kΩ
10
1039.0Ω 1779Ω 41.34 kΩ
20
1077.9Ω 1204Ω 26.97 kΩ
25
1097.3Ω 1000Ω 22.00 kΩ
30
1116.7Ω 833.7Ω 18.03 kΩ
40
1155.4Ω 589.0Ω 12.30 kΩ
50
1194.0Ω 423.9Ω 8.57 kΩ
60
1232.4Ω 310.5Ω 6.07 kΩ
70
1270.7Ω 231.0Ω 4.38 kΩ
80
1308.9Ω 174.5Ω 3.21 kΩ
90
1347.0Ω 133.6Ω 2.39 kΩ
100
1385.0Ω 103.6Ω 1.80 kΩ
** For a PT100 RTD, divide the PT1000 values by 10
